Laminar Flow and Containment Equipment
Dual-Operator Laminar Flow Clean Bench
A wide clean bench with a continuous filtered work area that gives two operators independent reach zones without dividing the protected surface.
- Two Independent Reach Zones
- Continuous Clean Worktop
- Wide Uniform Air Supply
- Split Utility Access
Product Introduction
The dual-operator bench extends the filter, diffuser and worktop across two working positions. Each operator receives a dedicated lighting and utility area while the continuous stainless surface supports shared trays or long assemblies. Internal fan balancing keeps the air supply even across the wider span, and a stiffened front beam limits deflection above the opening. The design is for non-hazardous product-protection work requiring coordinated two-person handling.
Key Features
Separate utility panels reduce hose and cable crossing over shared work.
The continuous stainless worktop supports long assemblies and coordinated transfers.
Dual lighting sections reduce shadows created by two operators working side by side.
A reinforced front beam maintains sash alignment across the wider cabinet opening.
Customer Product Concerns
A two-person clean bench must preserve uniform airflow across a wide opening while separating utilities and operator movements.
Air velocity drops at the center of a wide work zone.Balanced fan branches and a continuous diffuser distribute supply across both positions.
Cables from two operators cross the shared process area.Left and right service panels keep utilities within each operator's reach zone.
A jointed worktop interrupts long assemblies.A continuous reinforced stainless surface spans the dual working width.
The long sash rail can sag and bind.A stiffened front structure supports accurate sash travel across the full opening.
Typical Applications
Large medical-device assemblyTwo-person sterile set preparationLong optical component handlingCollaborative electronics inspection
Technical Parameters
Typical configurable construction ranges for a dual-operator laminar flow clean bench are listed below.
| Core Material | SUS304 continuous work surface with reinforced powder-coated steel enclosure and mineral-wool acoustic infill |
|---|---|
| Panel Thickness | 30-50 mm reinforced double-skin sections |
| Effective Width | 1500-2400 mm clear working width |
| Maximum Length | Up to 2600 mm overall bench width |
| Steel Facing Thickness | 1.0-1.2 mm outer steel; 1.2-1.5 mm SUS304 worktop |
| Core Density | 80-120 kg/m³ mineral-wool acoustic infill |
| Thermal Conductivity | 0.035-0.045 W/(m·K) for the mineral-wool infill |
| Surface Finish | White powder-coated enclosure with brushed continuous SUS304 work surface |
| Joint Type | Reinforced sealed cabinet seams with a full-width filter clamp and continuous worktop support |
| Customization | Available based on the intended application and operating environment. |
Available Options
Two independent utility panelsMotorized full-width sashDual blower monitoringSit-stand base configuration
Planning a Dual-Operator Laminar Flow Clean Bench specification?
Send us your dimensions, installation conditions, performance targets and required surface finish.
