Silica Rock Cleanroom Sandwich Panel

A steel-faced cleanroom panel with a rigid silica-based inorganic core, offering a hard surface-supporting center, low moisture uptake and stable modular construction for hygienic walls and ceilings.

Rigid Silica Mineral Core
Low Moisture Uptake
Hard Compression-Resistant Center
Clean Steel Surface

Request a Quote Browse Products

Product Introduction

Silica Rock Cleanroom Sandwich Panels place a pressed inorganic core made from silica-rich mineral material and magnesium-based binders between coated steel sheets. Unlike fibrous insulation, the hard core provides continuous support beneath the outer skins and resists local compression. Its relatively low water absorption makes the material useful in controlled areas with moderate humidity. Precision edge profiles close the mineral center and create straight modular joints. The result is a solid, wipeable partition or ceiling panel suited to cleanrooms that favor inorganic construction and firm surface support.

Key Features

A pressed silica-rich core provides continuous support beneath both external steel faces.

Hard mineral structure resists localized compression better than low-density foam or paper cells.

Low moisture uptake helps maintain panel dimensions in normal humid cleanroom service.

Enclosed edges prevent mineral dust from reaching the controlled room.

Machine-formed joints align quickly and leave a narrow hygienic sealant line.

Customer Product Concerns

Customers focus on mineral dust containment, core brittleness, panel mass and the protection of cut edges.

A brittle inorganic core can chip when a panel is cut carelessly on site.Factory sizing and finished cut-outs reduce uncontrolled edge damage.

Mineral dust must never enter a controlled environment through unfinished openings.Steel skins and sealed closure profiles isolate every exposed core surface.

Dense panels require more careful lifting than lightweight foam modules.Balanced lifting points and practical module lengths protect both workers and panel edges.

Surface impacts can crack an unsupported facing over a void.The continuous rigid core supports the skin across the full panel area.

Typical Applications

Pharmaceutical cleanroom wallsMedical-device production roomsLaboratory partitionsFood-processing clean areasElectronics manufacturing ceilings

Technical Parameters

Common specifications for silica rock cleanroom panels are shown below.

Core Material	Rigid silica rock inorganic composite
Panel Thickness	50, 75, 100 or 150 mm
Effective Width	950 or 1150 mm
Maximum Length	6000 mm
Steel Facing Thickness	0.40–0.70 mm
Core Density	80–100 kg/m³
Thermal Conductivity	Approximately 0.050 W/(m·K)
Surface Finish	PE-, HDP- or PVDF-coated galvanized steel
Joint Type	Tongue-and-groove, cam-lock or framed aluminum connection
Customization	Available based on the intended application and operating environment

Available Options

Alternative mineral formulationStainless steel facingHandmade or machine-made edgeFactory-cut openings
