Cleanroom Garments, PPE and Consumables
Cleanroom Tape
Blue polyethylene cleanroom tape with a low-outgassing acrylic adhesive and plastic core for temporary sealing, marking and color coding.
- Conformable polyethylene backing for clean sealing and marking
- Low-residue pressure-sensitive adhesive
- Plastic-core roll prepared for controlled-area transfer
Product Introduction
Cleanroom Tape replaces uncontrolled office tape in packaging, maintenance and in-process identification tasks. Its smooth polyethylene backing conforms to bags, bins and curved components while limiting fiber release. A pressure-sensitive acrylic adhesive provides dependable temporary attachment and clean removal from qualified smooth substrates, and the plastic core avoids exposed paperboard at the center of the roll.
Key Features
Silicone-free acrylic adhesive supports low-residue removal
Hand-conformable film follows corners and irregular surfaces
Writable blue surface enables temporary coding with a qualified marker
Clean processing and double-bag options simplify area transfer
Customer Product Concerns
General-purpose tapes may introduce paper fibers, adhesive transfer or uncontrolled plasticizers. The selected cleanroom tape must also balance peel strength with removability on the actual surface and throughout the required dwell time.
Adhesive residue can remain on stainless steel, plastic bins or equipment panels.Qualify a low-adhesion acrylic grade on each substrate and removal interval.
A stiff backing may lift around corners and curved packaging.Use a conformable polyethylene film and apply without trapped tension.
Paper cores can shed particles during dispensing.Specify a clean plastic core and controlled double-bagged presentation.
Excessive stretching can distort color-coded boundary lines.Unwind at a steady rate and press the tape down progressively with light pressure.
Typical Applications
Used for clean bag sealing, temporary equipment marking, bin identification, floor and bench coding, component protection, plate sealing and in-process work in controlled manufacturing or laboratory areas.
Technical Parameters
The ranges below describe a common low-adhesion polyethylene cleanroom tape. Final width, color, adhesive level and clean packaging should match the sealing or identification process.
| Core Material | Low-density polyethylene film with silicone-free acrylic pressure-sensitive adhesive |
|---|---|
| Panel Thickness | 0.13-0.15 mm total tape thickness |
| Effective Width | 12-76 mm roll width |
| Maximum Length | 32900 mm roll length |
| Steel Facing Thickness | 0 mm; no steel facing used |
| Core Density | 910-940 kg/m³ LDPE backing |
| Thermal Conductivity | 0.30-0.42 W/(m·K), polyethylene grade dependent |
| Surface Finish | Smooth matte blue writable polyethylene film |
| Joint Type | Single-sided pressure-sensitive acrylic adhesive wound on plastic core |
| Customization | Available based on the intended application and operating environment. |
Available Options
Blue, white, red, green or yellow filmLow, medium or higher adhesion grade12-76 mm slit widthsAcrylic or silicone-free synthetic-rubber adhesiveNon-irradiated or irradiated presentationIndividual or double-bagged roll packaging
Planning a Cleanroom Tape specification?
Send us your dimensions, installation conditions, performance targets and required surface finish.
