Cleanroom Garments, PPE and Consumables
Cleanroom Double-Sided Tape
Clear double-sided cleanroom tape with acrylic adhesive and a red polypropylene release liner for controlled temporary mounting and joining.
- Clear film carrier coated with acrylic adhesive on both faces
- Red polypropylene release liner supports clean handling
- Removable grade for temporary mounting and fixture control
Product Introduction
Cleanroom Double-Sided Tape creates concealed bonds without introducing exposed paper backing. A dimensionally stable clear film carrier is adhesive coated on both sides and protected by a red polypropylene liner until application. The removable acrylic grade supports temporary fixtures, signs, films and process aids while enabling clean separation from qualified smooth substrates.
Key Features
Red polymer liner is easy to identify and peel during installation
Removable acrylic adhesive permits repositioning during setup
Stable carrier supports accurate slit edges and die-cut parts
Controlled processing and clean packaging limit loose contamination
Customer Product Concerns
Double-sided mounting materials can be difficult to position because the second adhesive face is hidden during assembly. Residue, liner fragments and uncontrolled bond strength may also complicate changeover in sensitive work areas.
Thin clear tape can be difficult to see during liner removal.Use a contrasting red polypropylene liner and controlled peel tab.
Misalignment may trap the adhesive before the fixture is positioned.Apply one face first, align the assembly, then remove the second liner progressively.
Excessive dwell can increase removal force on delicate surfaces.Qualify removable adhesive against the actual substrate and planned dwell time.
Rough or contaminated substrates can reduce effective contact area.Clean and dry compatible surfaces and use firm uniform application pressure.
Typical Applications
Suitable for temporary sign and nameplate mounting, plastic-film joining, process-fixture attachment, cleanroom construction aids, electronics assembly masks and removable positioning of smooth lightweight components.
Technical Parameters
These values describe a thin removable double-coated tape for cleanroom mounting. Final carrier, width, peel strength and liner configuration should be chosen for the bonded materials and removal schedule.
| Core Material | Clear polymer film carrier with removable acrylic adhesive on both faces |
|---|---|
| Panel Thickness | 0.08-0.10 mm excluding release liner |
| Effective Width | 12-76 mm roll width |
| Maximum Length | 32900 mm roll length |
| Steel Facing Thickness | 0 mm; no steel facing used |
| Core Density | 1350-1400 kg/m³ clear film carrier |
| Thermal Conductivity | 0.15-0.24 W/(m·K), carrier and adhesive dependent |
| Surface Finish | Clear double-coated film with smooth red polypropylene release liner |
| Joint Type | Pressure-sensitive acrylic adhesive on both faces with peel-away liner |
| Customization | Available based on the intended application and operating environment. |
Available Options
Removable or permanent acrylic adhesiveClear, red or blue polymer release liner12-76 mm slit widthsRoll, sheet or precision die-cut formatThin film or closed-cell foam carrierClassic-clean or higher-cleanliness packaging
Planning a Cleanroom Double-Sided Tape specification?
Send us your dimensions, installation conditions, performance targets and required surface finish.
