Laminar Flow and Containment Equipment

Mobile Laminar Flow Hood

A wheeled clean-air enclosure that can be positioned over a table or compact instrument to provide temporary filtered product protection.

Lockable Mobile Frame
Compact Fan-Filter Module
Clear Flexible Enclosure
Roll-Over Process Positioning

Request a Quote Browse Products

Product Introduction

This hood combines a light tubular frame, fan-filter module and clear side enclosure on cleanroom-compatible casters. The open lower frame can straddle a fixed workbench or small machine, allowing the filtered zone to be brought to the process rather than moving the process itself. Locking casters and leveling pads stabilize the unit during use. The hood is intended for temporary non-hazardous product protection and is connected to facility power at its operating position.

Key Features

An open-base frame can roll around existing tables and compact instruments.

Non-marking locking casters secure the hood after positioning.

Clear side panels show the process while restricting lateral room drafts.

A top fan-filter module keeps the lower access area free of equipment.

Quick-release curtain or panel mounts simplify relocation and cleaning.

Customer Product Concerns

A movable hood must pass through doors, clear installed equipment and remain stable enough for repeatable airflow at the destination.

Sensitive equipment cannot be moved to a fixed clean bench.The open lower frame rolls over the installed process location.

Caster movement changes the working height.Locking casters and adjustable pads stabilize the frame at its final position.

A wide hood cannot pass through standard doorways.A narrow modular frame and removable panels support controlled relocation.

Loose curtains contact the process during movement.Quick-release curtains can be secured or removed before the hood is rolled.

Typical Applications

Temporary clean assemblyInstrument maintenance under filtered airBatch changeover protectionClean component staging

Technical Parameters

Typical configurable construction ranges for a mobile laminar flow hood are listed below.

Core Material	Anodized aluminum tubular frame with powder-coated steel fan-filter housing and clear PVC or polycarbonate panels
Panel Thickness	20-40 mm framed enclosure sections
Effective Width	800-1800 mm clear protected width
Maximum Length	Up to 2400 mm overall mobile height
Steel Facing Thickness	0.8-1.0 mm powder-coated fan-filter housing
Core Density	Approximately 1200 kg/m³ for solid polycarbonate enclosure panels
Thermal Conductivity	0.19-0.22 W/(m·K) for polycarbonate panels
Surface Finish	Natural anodized frame, white filter housing and clear cleanroom-grade enclosure panels
Joint Type	Quick-release modular frame with gasketed fan-filter mount and lockable caster bases
Customization	Available based on the intended application and operating environment.

Available Options

Rigid or flexible side panelsBattery-backed fan operationHeight-adjustable frameAntistatic clear curtains

Planning a Mobile Laminar Flow Hood specification?

Send us your dimensions, installation conditions, performance targets and required surface finish.
