Cleanroom Furniture and Stainless Steel Products
Cleanroom Goggle Washing Sink
A Type 316L manual goggle-cleaning station with a divided coved bowl, removable blue mesh baskets, low-pressure rinse spray, lens-separation rack and protected filtered-air manifold.
- Separated wash and rinse zones
- Blue soft-mesh goggle baskets
- Low-pressure fan rinse spray
- Protected filtered-air manifold
Product Introduction
The cleanroom goggle washing sink organizes manual processing of reusable protective eyewear without confusing the station with an emergency eyewash. A central divider separates detergent wash from low-pressure rinse water. Two removable blue polymer mesh baskets prevent lenses from contacting the stainless bowl, while a silicone-coated rack holds goggles individually during inspection and draining. The side-mounted fan spray controls rinse impact, and a guarded filtered-air manifold assists surface water removal without directing an exposed high-velocity nozzle at the lenses.
Key Features
Soft blue mesh baskets support goggles without metal-to-lens contact and lift out for batch transfer.
Silicone-coated separators hold individual goggles apart so straps and lenses remain visible during inspection.
A perforated guard distributes filtered drying air across the rack rather than concentrating it at one lens.
Customer Product Concerns
Reusable goggles need gentle separation through washing, rinsing and draining so lenses are not scratched, straps do not tangle and residual liquid is not trapped under stacked eyewear.
Loose goggles rub against a stainless bowl and scratch coated lenses.Removable soft blue mesh baskets isolate the eyewear from hard wetted surfaces.
Wash chemistry carries into the final rinse when every step uses one undivided basin.The welded center divider creates distinct wash and low-pressure rinse zones.
Nested goggles retain liquid between lenses, frames and elastic straps.The silicone-coated separation rack holds each item open and individually spaced.
A concentrated air jet lifts lightweight eyewear or damages anti-fog coatings.The guarded perforated manifold distributes low-pressure filtered air over the whole rack.
Typical Applications
Reusable cleanroom goggle processingControlled-environment eyewear change roomsPharmaceutical laundry supportBiotechnology PPE preparationHigh-care eye-protection wash areas
Technical Parameters
Typical configurable specifications for a manual cleanroom goggle washing sink are listed below.
| Core Material | Type 316L stainless divided wash bowl with blue polypropylene mesh baskets and silicone-coated stainless goggle rack |
|---|---|
| Panel Thickness | 1.5 mm welded bowl, divider, splashback and enclosed service panel |
| Effective Width | 1000 mm overall wash-and-rinse working width |
| Maximum Length | 600 mm maximum front-to-back sink depth |
| Steel Facing Thickness | 1.5 mm Type 316L stainless wetted surfaces |
| Core Density | 7950–8050 kg/m³ for Type 316L stainless steel |
| Thermal Conductivity | 13–16 W/(m·K) for Type 316L stainless steel |
| Surface Finish | Satin-brushed exterior, smooth coved bowl, blue soft-mesh baskets and silicone-coated separators |
| Joint Type | Fully welded divided bowl with quick-lift baskets, low-pressure fan-rinse connection, guarded air manifold and twin 38 mm wastes |
| Customization | Available based on the intended application and operating environment. |
Available Options
Anti-fog dosing cupHeated purified-water rinseTimed filtered-air supplyAdditional removable goggle rack
Planning a Cleanroom Goggle Washing Sink specification?
Send us your dimensions, installation conditions, performance targets and required surface finish.
