Cleanroom Doors, Windows and Interlock Systems
Three-Door Cleanroom Interlock System
A three-channel airlock control package for vestibules with one common entrance and two controlled exits, or other cleanroom routes requiring defined three-door sequencing.
- Three Independent Door Channels
- Branching Airlock Logic
- Configurable Door Groups
- Individual Status Indication
Product Introduction
The three-door interlock system extends standard airlock logic to a branching layout. Each door has its own closed-position input, release output and request/status station, while the controller defines which combinations must remain mutually exclusive. This supports a common entry serving two process rooms, a personnel-and-material branch, or a three-sided transfer vestibule. Channel-specific indication helps occupants identify which route is available rather than treating every locked condition as the same fault.
Key Features
Programmable grouping permits all-door mutual exclusion or selected route combinations.
Individual status outputs identify the requested door and the channel currently blocking release.
Separate held-open timers reveal which of the three doors has exceeded its permitted opening time.
Customer Product Concerns
Three-door layouts require unambiguous route logic because a simple pairwise interlock can create unintended releases or lock every exit unnecessarily.
A common entrance serves two clean rooms with different access paths.Three discrete channels apply the release rule to the selected branch instead of wiring separate controllers independently.
Users cannot tell which of two destination doors is available.Door-specific request and status indication shows each branch state locally.
Independent two-door relays create conflicting logic around the shared door.One controller evaluates all three door contacts before issuing any lock release.
Typical Applications
Branching personnel airlocksThree-sided material vestibulesShared gowning-room exitsLaboratory corridor transfer nodes
Technical Parameters
Typical construction and interface ranges for a three-door cleanroom interlock system are listed below.
| Core Material | Three-channel programmable controller, power supply, relays, door contacts and operator stations |
|---|---|
| Panel Thickness | 90–150 mm controller enclosure depth |
| Effective Width | 240–320 mm controller enclosure width |
| Maximum Length | 400 mm controller enclosure height |
| Steel Facing Thickness | 1.0–1.5 mm steel cabinet; stainless operator plates typically 1.2–2.0 mm |
| Core Density | Approximately 1800–1920 kg/m³ for the three-channel glass-reinforced PCB laminate |
| Thermal Conductivity | Approximately 0.4–0.7 W/(m·K) for the channel-control PCB laminate |
| Surface Finish | Powder-coated control enclosure with labeled terminals and cleanroom-compatible operator stations |
| Joint Type | Three hardwired door channels with configurable grouping, common emergency input and auxiliary dry contacts |
| Customization | Available based on the intended application and operating environment |
Available Options
All-door or branch-specific exclusion logicThree touchless request stationsIndependent door-held alarmsAccess-control and BMS status contacts
Planning a Three-Door Cleanroom Interlock System specification?
Send us your dimensions, installation conditions, performance targets and required surface finish.
