Modular Clean Operating Room

A prefabricated operating-room envelope combining sealed wall and ceiling modules with a hermetic entrance, flush observation glazing and integrated service interfaces.

Replaceable Wall Modules
Hermetic Sliding Entrance
Flush Observation Glazing
Ceiling Airflow Integration

Request a Quote Browse Products

Product Introduction

The modular clean operating room is built around a galvanized support frame fitted with factory-finished wall and ceiling elements. Smooth coated metal surfaces, sealed narrow joints and flush-mounted glazing form an accessible room envelope while removable modules retain access to concealed services. The coordinated system accommodates a hermetic sliding door, ceiling airflow terminal, recessed lighting and a local control interface without relying on projecting site-built finishes.

Key Features

Individually removable wall elements provide service access without dismantling the entire room lining.

A hermetic sliding entrance and flush observation window reduce projecting ledges around high-use openings.

The modular ceiling grid accepts a central filtered-air supply canopy and recessed luminaires within a coordinated plane.

Powder-coated metal facings, sealed joints and stainless edge trims provide durable wipeable room surfaces.

Customer Product Concerns

Operating-room fit-outs must integrate openings, airflow and services while keeping finished surfaces accessible for cleaning and future alteration.

Conventional site-built walls can conceal utilities behind finishes that are difficult to reopen.Replaceable panels mounted to a support frame provide planned access to the service cavity.

Door frames, windows and control boxes can create projecting ledges and irregular joints.Coordinated flush frames and sealed perimeter details align built-in elements with the wall plane.

Ceiling airflow terminals and lighting are often coordinated after the room envelope is installed.A modular ceiling layout reserves defined interfaces for the central airflow canopy and recessed light panels.

Renovation may require extensive demolition when clinical layouts change.Demountable wall and ceiling elements allow selected modules to be replaced or reconfigured around retained framing.

Typical Applications

General and specialty hospital operating roomsDay-surgery and interventional procedure suitesHospital clean corridors and preparation areasOperating-room renovation within existing structural shells

Technical Parameters

Typical configurable construction values for a prefabricated metal-faced modular operating-room envelope are listed below.

Core Material	Rigid PIR insulation between coated steel facings on a galvanized steel support substructure
Panel Thickness	50-100 mm insulated wall and ceiling modules
Effective Width	1000-1200 mm nominal wall-module grid
Maximum Length	Up to 4000 mm single wall-element height
Steel Facing Thickness	0.8-1.0 mm powder-coated galvanized or stainless steel facing
Core Density	35-40 kg/m³ rigid PIR insulation
Thermal Conductivity	0.022-0.026 W/(m·K) for the PIR core
Surface Finish	Smooth powder-coated metal or satin stainless steel with flush glazing and cleanable sealed edges
Joint Type	Concealed panel fixing to steel rails with narrow sealed vertical joints and coved perimeter transitions
Customization	Available based on the intended application and operating environment.

Available Options

Powder-coated steel, stainless steel, HPL or glass wall finishesAutomatic sliding or hinged hermetic entrance configurationsObservation glazing with optional integral privacy blindIntegrated ceiling airflow, lighting and room-control interfaces
