Low-Temperature Cold-Room Air Shower

A thermally insulated personnel air shower with cold-rated door seals, moisture-resistant interior surfaces and drainable returns for chilled controlled areas.

Thermally Insulated Shell
Cold-Temperature Seals
Drainable Return Path
Condensation-Aware Design

Request a Quote Browse Products

Product Introduction

The cold-room air shower combines garment cleaning with a shell designed to control heat gain and condensation at a chilled entrance. Closed-cell insulated panels and thermally separated door frames limit cold bridging, while stainless interior surfaces and sloped return areas accommodate moisture from temperature transitions. The filtered air circuit can be configured for demand operation to limit unnecessary fan runtime between entries.

Key Features

Thick closed-cell insulation reduces temperature transfer through the enclosure walls.

Thermal-break door framing helps reduce cold bridging at frequently used openings.

Low-temperature gaskets retain flexibility through repeated chilled cycles.

Sloped stainless return areas guide condensate away from removable prefilters.

Demand-based operation can reduce heat input from fan running time.

Customer Product Concerns

Temperature transitions introduce condensation, heat leakage and stiff door seals that are not addressed by a standard dry-room air shower.

Warm humid air condenses on cold internal metal.Closed-cell insulation and thermal breaks help stabilise exposed surface temperatures.

Ordinary gaskets harden during low-temperature cycling.Flexible low-temperature elastomer seals maintain compression around the door frame.

Condensate reaches the prefilter area.Sloped stainless return trays direct moisture away from the filter cassette.

Continuous blower running adds heat to the chilled room.Demand-based controls limit shower fan operation between personnel cycles.

Typical Applications

Chilled food processingCold-chain pharmaceutical storageRefrigerated packaging roomsDairy hygiene entrances

Technical Parameters

Typical insulated construction ranges for a low-temperature personnel air shower are listed below.

Core Material	PIR-insulated stainless enclosure with low-temperature seals, drainable prefilter returns and H13 HEPA recirculation
Panel Thickness	75-100 mm closed-cell insulated panels
Effective Width	900-1500 mm clear cold-room passage width
Maximum Length	Up to 2500 mm insulated chamber length
Steel Facing Thickness	1.0-1.2 mm stainless internal facing with insulated external skin
Core Density	40-45 kg/m³ rigid PIR insulation
Thermal Conductivity	0.021-0.026 W/(m·K) for the closed-cell PIR core
Surface Finish	Brushed stainless interior with light-colour insulated exterior panels
Joint Type	Cam-lock thermal-break panel joints with low-temperature gaskets and sealed door-frame interfaces
Customization	Available based on the intended application and operating environment.

Available Options

75 mm or 100 mm PIR shellHeated door-frame perimeterStainless sloped drain panCold-rated motor and control enclosure
