Estação de Preparação de PCR

A positive filtered-air workstation that provides an organized clean zone for pre-amplification reagent and master-mix preparation.

Positive Filtered Work Zone
UV-Compatible Interior
Pre-Amplification Workflow
Pipette and Reagent Organization

Solicite um orçamento. Browse produtos

Introdução do produto

The PCR preparation workstation is dedicated to clean pre-amplification setup rather than biological containment. Filtered positive airflow reduces particle entry, while a closed front cover can shield the interior between sessions. UV-resistant side panels, a stainless work tray and removable pipette racks support cleaning and organized reagent handling. A timed UV lamp may be included for surface exposure when the cabinet is closed and unoccupied, but it does not replace validated cleaning procedures.

Características-chave

Positive filtered air reduces room-borne particle entry during reagent preparation.

A dedicated layout separates clean pipettes, tubes and reagent staging positions.

UV-resistant enclosure materials tolerate timed surface-exposure cycles.

A closed cover prevents direct user exposure while the UV lamp is operating.

The lift-out stainless tray exposes the lower surface after spills.

Preocupações do produto do cliente

Pre-amplification work is vulnerable to carryover contamination, but a clean PCR station must not be confused with a biological safety cabinet.

Amplified material is brought into the clean setup area.Dedicated storage and clear workflow labeling support a one-way pre-amplification process.

Pipettes and tubes are placed randomly across the work surface.Removable racks create defined clean and in-use positions.

UV light reaches the operator through an open front.The timed lamp operates only with the protective cover closed and the station unoccupied.

Users expect protection from hazardous aerosols.Application guidance limits the workstation to non-hazardous clean preparation.

Aplicações típicas

PCR master-mix preparationPre-amplification reagent setupMolecular diagnostic kit assemblyClean pipetting of non-hazardous samples

Parâmetros técnicos

Typical configurable construction ranges for a PCR preparation workstation are listed below.

Material principal	SUS304 work tray with powder-coated steel filter housing and UV-resistant polycarbonate enclosure panels
Painel de espessura	20-35 mm framed enclosure sections
Largura efetiva	600-1200 mm clear working width
Comprimento máximo	Up to 900 mm overall workstation depth
Aço enfrentando espessura	0.8-1.0 mm filter housing; 1.0-1.2 mm SUS304 work tray
Densidade Core	Approximately 1200 kg/m³ for solid polycarbonate enclosure panels
Condutividade térmica	0.19-0.22 W/(m·K) for polycarbonate panels
Superfície acabado	White powder-coated housing, clear UV-resistant panels and brushed stainless work tray
Tipo conjunto	Gasketed modular enclosure with lift-out work tray and interlocked front cover
Customização	Disponível com base na aplicação pretendida e no ambiente operacional.

Opções disponíveis

HEPA or ULPA supply filterTimed UV lamp with cover interlockPipette and tube racksBenchtop or base-stand format
