Cleanroom Furniture and Stainless Steel Products
Stainless Steel Trolley
An open Type 304 stainless service trolley with three reinforced marine-edge shelves, a continuously welded round-tube frame, twin push handles and four blue polyurethane swivel casters.
- Three marine-edge shelves
- Two-direction push handles
- Crevice-reduced round-tube frame
- Four blue polyurethane casters
Product Introduction
The stainless steel trolley carries small tools, sealed components and replenishment stock between controlled work areas while keeping every load level visible. Three solid Type 304 shelves are reinforced below and formed with a shallow marine edge that resists items sliding during movement. The round-tube frame is continuously welded and finished without open tube ends. Push handles at both ends allow the operator to change direction without turning the trolley in a narrow corridor, and four 125 mm blue polyurethane swivel casters include two total-lock brakes for stable parking.
Key Features
Shallow marine edges restrain loose containers without creating deep corners around the shelf surface.
Twin rounded push handles support controlled movement from either end through narrow transfer routes.
Blue non-marking polyurethane wheels combine quiet rolling with two total-lock positions for loading stability.
Customer Product Concerns
Routine cleanroom transport needs open visibility, contained shelf loads and predictable maneuvering without exposed frame cavities or black-marking industrial wheels.
Loose trays migrate toward a shelf edge when the trolley crosses a threshold.Each solid shelf has a formed marine perimeter that limits lateral movement.
A single handle forces operators to turn a loaded cart in a confined corridor.Rounded handles at both ends permit immediate push control in either direction.
Open tube ends and bolted frame corners retain cleaning residue.Continuously welded round tubes use sealed ends and blended junctions.
Hard wheels transmit vibration and leave visible marks on resilient cleanroom flooring.125 mm blue polyurethane casters provide a compliant non-marking rolling surface.
Typical Applications
Cleanroom consumable replenishmentLaboratory tool transferPharmaceutical component movementMedical-device assembly supportControlled packaging material delivery
Technical Parameters
Typical configurable specifications for a three-shelf stainless cleanroom trolley are listed below.
| Core Material | Type 304 stainless solid shelves, round-tube frame and push handles with blue polyurethane caster treads |
|---|---|
| Panel Thickness | 1.2 mm solid shelf panels with welded underside reinforcement |
| Effective Width | 900 mm usable shelf length |
| Maximum Length | 1000 mm maximum overall trolley length including push handles |
| Steel Facing Thickness | 1.2 mm Type 304 shelf sheet; 1.5 mm round-tube wall |
| Core Density | 7900–8000 kg/m³ for Type 304 stainless steel |
| Thermal Conductivity | 14–17 W/(m·K) for Type 304 stainless steel |
| Surface Finish | Uniform satin-brushed stainless surfaces with passivated welds and blue non-marking wheel treads |
| Joint Type | Continuously welded round-tube frame with reinforced marine-edge shelves and threaded caster-stem sockets |
| Customization | Available based on the intended application and operating environment. |
Available Options
Type 316L stainless constructionPerforated middle shelfRemovable blue shelf matsConductive casters and grounding chain
Planning a Stainless Steel Trolley specification?
Send us your dimensions, installation conditions, performance targets and required surface finish.
