Personnel and Material Decontamination Equipment
Integrated Hand Wash, Dry and Sanitizing Station
A single stainless steel station that presents touchless hand washing, drying and sanitizing in a defined entry sequence.
- Three-stage hand hygiene route
- Touchless wash controls
- Enclosed drying module
- Separated wet and sanitizer circuits
Product Introduction
The Integrated Hand Wash, Dry and Sanitizing Station places the hand-hygiene steps in one linear cabinet. Touchless soap and water outlets serve the wash stage, a drying module removes residual moisture, and enclosed hand ports provide the selected sanitizer at the final stage. The wet zone, air-drying or paper-drying section and solution reservoir areas are separated within the unit to make routine service more orderly.
Key Features
Touchless soap and water outlets reduce the need for users to touch wash controls.
A dedicated drying module can be configured for filtered air or paper towels.
Separate tubing and service compartments keep wash and sanitizer supplies apart.
The final module can provide a completion output to compatible entry equipment.
Customer Product Concerns
Separate wash, dry and sanitizer units can create unclear traffic flow and make it easy for users to miss a stage.
Personnel move from rinsing to the entrance with wet hands.The central drying stage is physically positioned between wash and sanitizing modules.
Unlinked devices create queues and crossing movement in a small airlock.A single linear cabinet provides one clearly ordered hygiene route.
Wash and sanitizer supplies are confused during refilling.Separated service compartments and fluid circuits identify each supply route.
A connected entrance needs to know whether the station sequence has finished.The control arrangement can deliver a completion output after the configured stages.
Typical Applications
Food and beverage clean productionPharmaceutical personnel entryMedical manufacturing hygiene roomsCosmetic filling facilitiesBiotechnology changing suites
Technical Parameters
The number of lanes, drying method and module order can be matched to throughput and the planned hygiene sequence.
| Core Material | SUS304 cabinet with stainless wash basin and enclosed drying and sanitizing modules |
|---|---|
| Panel Thickness | 1.2–1.5 mm stainless steel enclosure panels |
| Effective Width | 600–1000 mm operator working width |
| Maximum Length | 1800–2800 mm overall station length |
| Steel Facing Thickness | 1.2–1.5 mm SUS304 |
| Core Density | 7900–8000 kg/m³ for stainless steel |
| Thermal Conductivity | 14–16 W/(m·K) for stainless steel |
| Surface Finish | Brushed SUS304 with seamless basin and enclosed drying hand ports |
| Joint Type | Continuously welded wet-zone cabinet with gasketed utility service panels |
| Customization | Available based on the intended application and operating environment. |
Available Options
Filtered-air or paper-towel dryingSingle or two-lane layoutHeated-water supplyCompletion relay for connected equipment
Planning a Integrated Hand Wash, Dry and Sanitizing Station specification?
Send us your dimensions, installation conditions, performance targets and required surface finish.
