FFU Group Control Panel

A compact wall panel that gives one cleanroom zone coordinated start, stop, speed presets and fault indication without requiring a full central-control cabinet.

Dedicated Zone Operation
Group Speed Presets
Local Fault Indication
Compact Wall Enclosure

Request a Quote Browse Products

Product Introduction

The FFU group control panel operates a defined group of EC fan filter units serving one room or process zone. A small touchscreen or selector interface provides common start/stop and preset airflow levels, while addressable communication or isolated analogue outputs deliver commands to the connected fans. Status lamps and a summary alarm relay show whether the group is available without exposing the complexity of a facility-wide supervisory system. The panel can work independently or report its group state upward to a central controller.

Key Features

One zone command keeps neighbouring FFUs at a coordinated operating level.

Preset production, standby and boost modes reduce repeated manual adjustment.

A local summary alarm identifies communication or fan failure within the controlled group.

Compact low-voltage construction suits wall mounting near the served cleanroom.

Customer Product Concerns

A small FFU zone needs coordinated operation and fault visibility, but a large central cabinet can be disproportionate to the number of connected units.

Individual wall switches leave adjacent FFUs running at mismatched speeds.A shared group setpoint sends the same operating command to every fan in the zone.

Operators cannot tell whether a stopped unit is disabled or has a communication fault.Separate run and alarm indications distinguish normal standby from abnormal loss of feedback.

A small room cannot justify the space and wiring of a full supervisory cabinet.The compact wall enclosure combines low-voltage control, group display and field terminals.

Future central monitoring would require replacing the original local controls.An optional network port allows the group panel to become a subordinate zone node.

Typical Applications

Single cleanroom FFU zonesModular laboratory suitesClean booths and mini-environmentsGowning-room ceiling groupsIndependent production cells

Technical Parameters

Typical enclosure and control ranges for an FFU group control panel are shown below.

Core Material	Compact PLC or group controller with 24 VDC supply, zone HMI, alarm relay and isolated EC fan interfaces
Panel Thickness	120-200 mm wall-enclosure depth
Effective Width	300-500 mm nominal panel width
Maximum Length	Up to 600 mm enclosure height
Steel Facing Thickness	1.2-1.5 mm powder-coated steel enclosure and removable gland plate
Core Density	Approximately 1800-1900 kg/m³ nominal density of the FR-4 substrate used in the group control panel
Thermal Conductivity	Approximately 0.25-0.40 W/(m·K) through the group-panel FR-4 control substrate
Surface Finish	Cleanroom-white powder coat with flush dark HMI window and blue-green status indicators
Joint Type	Gasketed wall enclosure with detachable terminal blocks and RS-485 or isolated 0-10 V field connections
Customization	Available based on the intended application and operating environment.

Available Options

Touchscreen or selector-switch interfaceHardwired 0-10 V or addressable fan networkSummary alarm relayModbus subordinate connection

Planning a FFU Group Control Panel specification?

Send us your dimensions, installation conditions, performance targets and required surface finish.

Talk to Our Team
