Cleanroom Cleaning, Disinfection and Sterilization
Cleanroom Garment Washer
A hygienic barrier washing machine that transfers reusable cleanroom garments from a soiled loading area to a separated clean-side unloading area.
- Opposed loading and unloading doors protect zone separation
- Programmable wash profiles support technical garment care
- Flush stainless fascia simplifies clean-side housekeeping
Product Introduction
The cleanroom garment washer is a pass-through barrier unit for controlled laundering of coveralls, hoods, overshoes, and compatible textile accessories. Stainless process surfaces, opposed interlocked doors, automatic dosing connections, and configurable recipes support a documented laundry flow. Final cycle selection remains dependent on the garment supplier's care limits and the site's contamination-control procedure.
Key Features
Interlock prevents both drum doors opening together
Stainless-steel drum and clean-side fascia
Programmable wash, rinse, and extraction stages
Controlled detergent and additive dosing connections
Adjustable drum speed and reversing action
High-extraction configuration to reduce retained moisture
Partition seal interface for hygienic installation
Customer Product Concerns
Reusable cleanroom garments must be washed without uncontrolled contact between used and processed loads. Aggressive mechanical action, residual chemistry, and an unsuitable final rinse can shorten garment life or leave particles and extractables.
How is clean and soiled laundry kept apart?Opposed doors, a sealed partition interface, and door interlocking enforce a one-way transfer through the washer.
Can cycles protect technical fabrics?Programmable drum action, temperature, water level, extraction speed, and dosing allow recipes to follow garment care requirements.
How are detergent residues controlled?Metered dosing and configurable intermediate and final rinses allow chemistry removal targets to be built into the cycle.
Is the machine practical to clean?Flush stainless panels, accessible seals, drainable wetted surfaces, and service access outside the critical unload face support housekeeping.
Typical Applications
Pharmaceutical cleanroom laundriesSemiconductor garment processingMedical-device manufacturing facilitiesBiotechnology controlled areasElectronics cleanroom supportHospital sterile-service laundries
Technical Parameters
A horizontal perforated drum is accessed through interlocked doors on opposite sides of the machine. The washer can be sealed into a partition so incoming garments and washed garments follow a one-way route. Programmable water levels, temperature, drum action, dosing, extraction, and rinsing allow cycles to be matched to garment construction.
| Core Material | Stainless-steel drum and wetted components with reinforced steel frame |
|---|---|
| Panel Thickness | 30–50 mm insulated enclosure panels |
| Effective Width | 700–1200 mm drum and loading-face width |
| Maximum Length | 1200–2000 mm overall machine depth |
| Steel Facing Thickness | 1.0–2.0 mm stainless-steel facing |
| Core Density | 40–60 kg/m³ acoustic and thermal insulation where fitted |
| Thermal Conductivity | 0.035–0.045 W/(m·K) for insulated enclosure sections |
| Surface Finish | Brushed stainless clean-side fascia with smooth cleanable drum surfaces |
| Joint Type | Gasketed barrier flange, interlocked drum doors, welded wetted seams, and sanitary utility connections |
| Customization | Available based on the intended application and operating environment. |
Available Options
20–70 kg nominal dry-load capacitiesSteam or electric heatingAutomatic liquid chemical dosingPurified-water final rinseConductivity-monitored rinse endpointClean-side status displayData logging and batch reportsCustom partition trim and sealing kit
Planning a Cleanroom Garment Washer specification?
Send us your dimensions, installation conditions, performance targets and required surface finish.
