Paperless Chart Recorder

A multi-channel panel recorder that displays live cleanroom trends, stores measurements electronically and eliminates consumable chart paper.

Multi-Channel Color Trends
Internal Electronic Storage
Removable Data Export
Alarm Relay Outputs

Request a Quote Browse Products

Product Introduction

The paperless chart recorder accepts multiple temperature, humidity, pressure, voltage, current or contact signals and plots them as color traces on an industrial display. Internal memory stores time-stamped measurements, annotations and alarms, while removable media or Ethernet supports data export. Channel scaling converts standard inputs into engineering units so operators can compare related cleanroom conditions on the same time base. A panel-mount bezel places the screen at control cabinets and local monitoring stations without the paper, ink and mechanical drive of a traditional chart recorder.

Key Features

Color traces display multiple environmental and utility channels on a common time axis.

Electronic storage avoids chart-paper handling and records alarms with the measured values.

Universal or modular inputs accept common thermocouple, RTD, voltage and current signals.

Removable media and Ethernet provide practical methods for transferring recorded data.

Customer Product Concerns

A local recorder must keep channel identity, time and engineering units intact when data are viewed, exported or archived.

Paper charts run out or are difficult to store and search.Electronic memory stores indexed records without consumable media.

Different input types need separate instruments.Universal and modular channels combine standard environmental and process signals.

Exported files lose the channel names used by operators.Configured tags, units and timestamps travel with the recorded dataset.

An alarm is shown without the trend that led to it.Alarm markers remain linked to the corresponding time position on each trace.

Typical Applications

Cleanroom environmental trendingAHU process recordingUtility temperature monitoringLocal production data review

Technical Parameters

Typical construction values for an industrial paperless chart recorder are listed below.

Core Material	Industrial color LCD, FR-4 acquisition electronics and powder-coated steel rear chassis
Panel Thickness	120-260 mm recorder depth
Effective Width	144-300 mm front bezel width
Maximum Length	Up to 320 mm chassis dimension
Steel Facing Thickness	0.8-1.2 mm powder-coated steel rear chassis
Core Density	7800-8050 kg/m³ for steel chassis components
Thermal Conductivity	45-60 W/(m·K) for steel structural parts
Surface Finish	Black front bezel with full-color trend screen and light-gray coated rear chassis
Joint Type	Gasketed panel-mount bezel with removable input modules and rear terminal blocks
Customization	Available based on the intended application and operating environment.

Available Options

Universal analog input modulesRelay alarm cardUSB or SD data exportEthernet and Modbus communication
