Cleanroom Cleaning, Disinfection and Sterilization
Mobile VHP Decontamination Unit
All-in-one mobile VHP decontamination unit with dehumidification, peroxide vapor injection, catalytic aeration and electronic cycle capture.
- Automated four-phase VHP cycle
- Integrated dehumidification and aeration
- Mobile room and enclosure connections
Product Introduction
The Mobile VHP Decontamination Unit combines conditioning, vaporization, dwell control and catalytic aeration in one wheeled stainless cabinet. HEPA-filtered dry air prepares the target humidity, then a metering module injects peroxide vapor through locking supply and return hoses. Integrated sensors govern phase transitions, while the HMI stores recipes and captures cycle data for controlled reuse across rooms, isolators and chambers.
Key Features
Metered vapor injection controls peroxide delivery.
Catalytic aeration converts residual peroxide after dwell.
Pressure monitoring supports enclosure connections.
Touchscreen recipes reduce manual phase changes.
Electronic and optional printed records capture cycle events.
Customer Product Concerns
The unit addresses multi-device setup, shifting humidity, lengthy aeration and incomplete cycle documentation.
Multiple separate devicesConditioning, injection and aeration are consolidated in one unit.
Humidity variabilityIntegrated dry-air conditioning prepares the sealed target.
Slow room releaseCatalytic aeration accelerates peroxide removal.
Weak documentationStored recipes and electronic cycle capture preserve operating history.
Typical Applications
Small and medium cleanroomsIsolators and RABSPass-through chambersFreeze dryersBiosafety cabinets and incubators
Technical Parameters
The values below represent pharmaceutical-grade mobile systems for clean, dry, sealed rooms and process enclosures.
| Core Material | Stainless cabinet with fluoropolymer peroxide circuit and catalyst module |
|---|---|
| Panel Thickness | 1.2-1.5 mm enclosure panel thickness |
| Effective Width | 700 mm nominal cabinet width |
| Maximum Length | 1200 mm nominal unit length |
| Steel Facing Thickness | 1.2 mm nominal Type 304 stainless facing |
| Core Density | 7900 kg/m³ nominal stainless-steel density |
| Thermal Conductivity | 15 W/(m·K) nominal for stainless cabinet structure |
| Surface Finish | Brushed stainless exterior with sealed HMI |
| Joint Type | Sanitary clamp or locking supply-and-return hose couplings |
| Customization | Available based on the intended application and operating environment. |
Available Options
Integrated peroxide concentration sensorEnclosure pressure-monitor kit120 or 230 V electrical configurationSanitary clamp adaptor kitSecure electronic data package
Planning a Mobile VHP Decontamination Unit specification?
Send us your dimensions, installation conditions, performance targets and required surface finish.
