Laminar Flow and Containment Equipment

Mobile Laminar Flow Workstation

A complete wheeled clean bench with its own work surface, fan-filter module and organized utilities for clean tasks that move between production areas.

Integrated Stainless Worktop
Self-Contained Mobile Base
Onboard Utility Panel
Four-Point Caster Braking

Request a Quote Browse Products

Product Introduction

Unlike an open mobile hood, this workstation includes a rigid stainless worktop and enclosed mobile base. The fan-filter unit, lighting, outlets and controls move together as one assembly, so the working height and equipment layout remain consistent between compatible locations. Large swivel casters and push handles support controlled movement, while four brakes and optional leveling feet stabilize the bench during operation. The unit is for non-hazardous product-protection processes.

Key Features

The worktop, clean-air supply and utilities remain aligned during relocation.

An enclosed lower base protects electrical and control components from impact.

Large non-shedding casters roll over cleanroom floor joints with less vibration.

Side push handles keep hands away from the clean work opening during movement.

Four-wheel braking and leveling feet reduce bench movement during precision tasks.

Customer Product Concerns

A mobile workstation must retain a repeatable clean workspace after each move without exposing controls or disturbing delicate tools.

Moving a separate hood and table changes their alignment.The filtered enclosure and stainless worktop share one rigid mobile chassis.

Small casters transmit floor joints to sensitive instruments.Large cushioned cleanroom casters reduce vibration during relocation.

Cables trail across the route between rooms.Onboard cable storage and a single power inlet organize the utility connection.

The workstation shifts during detailed assembly.Four caster brakes and optional leveling pads lock the chassis at the work location.

Typical Applications

Flexible electronics assemblyMobile sterile component preparationCleanroom maintenance supportShort-run device packaging

Technical Parameters

Typical configurable construction ranges for a mobile laminar flow workstation are listed below.

Core Material	SUS304 worktop on a powder-coated steel mobile chassis with mineral-wool acoustic fan enclosure
Panel Thickness	30-50 mm double-skin fan and base enclosure sections
Effective Width	900-1500 mm clear working width
Maximum Length	Up to 2100 mm overall workstation height
Steel Facing Thickness	1.0-1.2 mm outer steel; 1.2-1.5 mm SUS304 worktop
Core Density	80-120 kg/m³ mineral-wool acoustic infill
Thermal Conductivity	0.035-0.045 W/(m·K) for the acoustic infill
Surface Finish	White powder-coated chassis with brushed SUS304 worktop and handles
Joint Type	Welded mobile base with gasketed fan-filter frame, bonded worktop and bolted caster plates
Customization	Available based on the intended application and operating environment.

Available Options

Battery or UPS moduleSit-stand work heightESD-safe work surfaceIntegrated drawers and service outlets

Planning a Mobile Laminar Flow Workstation specification?

Send us your dimensions, installation conditions, performance targets and required surface finish.

Talk to Our Team
