Personnel and Material Decontamination Equipment
Cleanroom Pass-Through Storage Cabinet
A full-height, double-door cabinet that stages packaged supplies on adjustable shelves between two controlled rooms.
- Full-height transfer volume
- Adjustable stainless shelves
- Opposed interlocked doors
- Floor-supported construction
Product Introduction
This Cleanroom Pass-Through Storage Cabinet turns a wall boundary into an organised restocking point for boxed consumables, trays and prepared materials. The cabinet's removable shelf system can be set for several small batches or cleared for taller containers. Interlocked doors maintain separated loading and collection sides, while the floor-supported cabinet body accommodates more stored material than a compact wall pass box.
Key Features
Shelf rails permit the storage layout to be changed without altering the cabinet body.
Solid or perforated shelf choices can suit different packages and wiping practices.
A reinforced base supports regularly loaded transfer volumes.
Opposing doors can be interlocked to separate loading from clean-side retrieval.
Customer Product Concerns
Facilities that transfer an entire shift's supplies need more volume and better organisation than a small pass box can provide.
Bulk cartons and several trays require repeated small-box transfers.The tall cabinet provides a larger vertical staging volume with configurable shelf positions.
Different supply batches are mixed on one open surface.Multiple shelf levels create separate loading zones inside the cabinet.
Frequent loading places substantial weight on a wall-mounted unit.A floor-supported base carries the stored load directly to the floor.
Both teams may open their side while replenishment is underway.The interlock sequence coordinates the loading and collection doors.
Typical Applications
Pharmacy consumable restockingMedical-device component stagingClean garment transferPackaged media storageLaboratory container replenishment
Technical Parameters
These ranges cover a typical full-height pass-through cabinet with adjustable stainless steel storage fittings.
| Core Material | SUS304 stainless steel cabinet enclosure with removable stainless steel shelves |
|---|---|
| Panel Thickness | 1.0–1.5 mm stainless steel cabinet and door panels |
| Effective Width | 800–1500 mm usable cabinet width |
| Maximum Length | 2000–2600 mm overall cabinet height |
| Steel Facing Thickness | 1.0–1.5 mm SUS304 |
| Core Density | 7900–8000 kg/m³ for stainless steel |
| Thermal Conductivity | 14–16 W/(m·K) for stainless steel |
| Surface Finish | Brushed No. 4 SUS304 with removable cleanable shelves |
| Joint Type | Sealed cabinet seams with opposed interlocked doors |
| Customization | Available based on the intended application and operating environment. |
Available Options
Solid or perforated shelvesShelf dividersVision-panel doorsFloor-flush or wall-clamping installation
Planning a Cleanroom Pass-Through Storage Cabinet specification?
Send us your dimensions, installation conditions, performance targets and required surface finish.
