Cleanroom Material Handling and Storage
Cleanroom Lift Table
A mobile stainless steel hydraulic scissor table for clean, ergonomic lifting and positioning of process loads.
- Mobile stainless steel single-scissor lifting platform
- Manual hydraulic foot pump without an electrical connection
- Braked non-marking casters for transfer and workstation positioning
Product Introduction
The cleanroom lift table combines a smooth stainless platform, welded mobile base and hydraulic single-scissor mechanism. A foot pump raises loads without electrical connections, while the push handle and braked polyurethane casters support transfer and stable positioning.
Key Features
Hydraulic lift reduces repetitive bending and manual lifting.
Solid platform accepts containers, trays and equipment.
Braked swivel casters stabilize the table at the workstation.
Multiple platform and service-height configurations are available.
Customer Product Concerns
Ergonomic load positioning in a sanitized area requires stable height adjustment, an inspectable lifting mechanism and positive wheel restraint during loading and work.
Operator strainAdjustable platform height brings loads closer to the working level.
Corrosion during sanitationStainless exposed components resist wet cleaning.
Cart movement during loadingWheel brakes secure the mobile base.
Hard-to-clean mechanismsOpen scissor geometry improves inspection and cleaning access.
Typical Applications
For lifting vessels, trays, packaged materials and equipment in pharmaceutical, medical, food, laboratory and controlled manufacturing areas.
Technical Parameters
Platform dimensions, scissor arrangement, lifting range, actuator type and wheel compound can be configured for the load, service height, floor and sanitation process.
| Core Material | AISI 304 stainless steel platform, scissor frame and base |
|---|---|
| Panel Thickness | 2.0–3.0 mm platform sheet |
| Effective Width | 450–600 mm |
| Maximum Length | Up to 1000 mm |
| Steel Facing Thickness | 2.0–3.0 mm |
| Core Density | 7930 kg/m³ nominal stainless steel density |
| Thermal Conductivity | Approximately 16.2 W/(m·K) at room temperature |
| Surface Finish | Brushed, passivated or electropolished stainless steel |
| Joint Type | Fully welded frame with pinned scissor pivots and hydraulic cylinder |
| Customization | Available based on the intended application and operating environment. |
Available Options
304 or 316 stainless steel, alternate capacities, single or double scissors, platform guards, conductive wheels and powered lift actuation are available.
