Cleanroom Furniture and Stainless Steel Products
Cleanroom Garment Cart
A mobile Type 304 stainless garment cart with a transparent blue antistatic cover, full-width hanging rail, raised lower shelf and four blue polyurethane swivel casters.
- Covered garment transfer
- Full-width stainless hanging rail
- Raised lower clean shelf
- Four blue swivel casters
Product Introduction
The cleanroom garment cart moves prepared gowns between laundry, storage and controlled gowning areas without leaving the garments exposed along the route. Its TIG-welded Type 304 tubular frame supports a full-width hanging rail and a raised solid lower shelf for sealed footwear packs. A transparent blue antistatic PVC cover closes with a vertical zipper while allowing a quick stock check. Four non-marking polyurethane swivel casters, including two total-lock wheels, keep the tall cart maneuverable and stable at the loading point.
Key Features
A full-width polished rail carries spaced hangers without intermediate uprights obstructing garment loading.
The raised stainless lower shelf separates packaged shoes and folded accessories from the floor.
Four blue polyurethane swivel casters support quiet movement, with two total-lock brakes for parking.
Customer Product Concerns
Garment transfer needs covered exposure control, orderly hanger spacing and stable mobility without turning the cart itself into a difficult-to-clean enclosure.
Prepared gowns collect airborne particles while crossing an uncontrolled corridor.A full-height zippered antistatic cover encloses the hanging zone during transport.
Long garments drag across footwear packs placed on the cart floor.The hanging rail and raised lower shelf create separate gown and accessory levels.
A tall loaded rack becomes unstable when garments are removed from one side.A wide welded base and two total-lock casters stabilize the cart at the issue point.
Hidden frame cavities retain lint after wipe-down.Sealed tubular ends and blended TIG joints remove open cavities from the supporting frame.
Typical Applications
Cleanroom laundry-to-gowning transferPharmaceutical garment replenishmentSemiconductor fab gown distributionMedical-device clean apparel logisticsControlled-area visitor garment staging
Technical Parameters
Typical configurable specifications for a covered stainless cleanroom garment cart are listed below.
| Core Material | Type 304 stainless tubular frame and rail with transparent blue antistatic PVC cover and blue polyurethane caster treads |
|---|---|
| Panel Thickness | 0.35 mm flexible antistatic PVC cover |
| Effective Width | 1100 mm usable hanging-rail width |
| Maximum Length | 1200 mm maximum overall cart length |
| Steel Facing Thickness | 1.5 mm stainless tube wall; 1.2 mm lower shelf sheet |
| Core Density | 7900–8000 kg/m³ for Type 304 stainless frame components |
| Thermal Conductivity | 14–17 W/(m·K) for Type 304 stainless components |
| Surface Finish | Satin-brushed stainless frame with clear blue antistatic cover and non-marking blue wheel treads |
| Joint Type | TIG-welded sealed tubular frame with bolted hanging-rail sockets, zippered cover and threaded caster stems |
| Customization | Available based on the intended application and operating environment. |
Available Options
Type 316L stainless frameFully transparent antistatic coverDouble hanging railConductive casters and grounding lead
Planning a Cleanroom Garment Cart specification?
Send us your dimensions, installation conditions, performance targets and required surface finish.
