Cleanroom Utility Systemen
Sanitär Edelstahl Rohre
Polished 316L hygienic tube runs and fabricated spools engineered for drainable clean-utility distribution with controlled welds and low-hold-up connections.
- Hygienic 316L flow path
- Orbital-weld-ready tube ends
- Drainable low-hold-up routing
Produkteinführung
Sanitary Stainless Steel Piping forms the product-contact backbone of purified-water, WFI, clean-steam and hygienic process systems. Straight tubes and prefabricated spools use controlled dimensions, smooth internal surfaces and repeatable weld preparation so field joints can be aligned, purged and inspected without creating avoidable crevices or pockets.
Key Features
Controlled tube outside diameter and wall
Mechanical-polish or electropolish options
Square-cut orbital-weld preparation
Prefabricated branch and return spools
Drain-slope and support coordination
Hygienic clamp termination options
Heat and surface traceability options
Kunden Produktbedenken
Reliable sanitary piping requires more than smooth tube: slope, weld penetration, support spacing, internal finish and branch geometry all influence drainage and cleanability.
Field joints become misaligned or internally steppedUse matched tube tolerances, square-cut ends and controlled orbital-weld fit-up.
Low points retain water after shutdownCoordinate spool geometry, supports and installed slope around defined drains.
Rough surfaces trap residues and accelerate rouge buildupSelect and verify an internal finish appropriate to the utility and cleaning regime.
Excess field welding extends shutdown workPrefabricate surveyed spool sections with planned weld and clamp breakpoints.
Typische Anwendungen
Purified Water distributionWater for Injection loopsClean-steam headersCIP and SIP circuitsHygienic product transfer
Technische Parameter
Tube standard, diameter, wall, surface grade, spool geometry and support arrangement are selected for pressure, temperature, drainage and installation constraints.
| Core Material | 316L stainless steel hygienic tube and fabricated spool components |
|---|---|
| Panel Dicke | Tube wall typically 0.89–2.77 mm |
| Effektive Breite | Tube outside diameter typically 6.35–152.4 mm |
| Maximale Länge | Straight tube length typically up to 6000 mm |
| Stahl facing Dicke | Fabricated support plate typically 1.5–3.0 mm |
| Kerndichte | 316L stainless steel density approximately 8000 kg/m³ |
| Thermische Leitfähigkeit | 316L stainless steel approximately 15 W/(m·K) at ambient temperature |
| Oberfläche Finish | Mechanically polished or electropolished internal surface with clean satin exterior |
| Gemeinsamer Typ | Orbital butt welds with hygienic clamp unions at planned service breakpoints |
| Customisierung | Verfügbar je nach beabsichtigter Anwendung und Betriebsumgebung. |
Verfügbare Optionen
ASME BPE, ISO or EN tube dimensionsMechanical-polish or electropolish gradePrefabricated branch spoolsHygienic clamp breakpointsSlope-matched supportsHeat tracing and insulation interfaceMaterial and weld documentation package
Planning a Sanitary Stainless Steel Piping specification?
Senden Sie uns Ihre Abmessungen, Installationsbedingungen, Leistungsziele und gewünschte Oberflächenveredelung.
