Branchenspezifische Reinraumausrüstung
Handwaschen und Desinfektionsstation
A touchless stainless station that guides both hands through automated washing and disinfection cycles over an integrated drained basin.
- Paired Wash Openings
- Paired Disinfection Openings
- Touchless Sensor Cycles
- Integrated Drained Basin
Produkteinführung
The hand wash and disinfection station combines two sensor-controlled wash chambers and two separate sanitizer chambers in one stainless console. Internal nozzles meter water and soap during washing, followed by a controlled disinfectant dose. The wide basin captures runoff, while the central display and lower service cabinet provide cycle settings and access to pumps, reservoirs and plumbing.
Key Features
Two separate disinfection openings reduce contact between wet and sanitized stages.
Touchless sensors start repeatable timed cycles without shared handles.
A deep sloped basin and concealed service cabinet simplify drainage and maintenance.
Kunden Produktbedenken
Manual sinks do not ensure that both hands receive consistent washing and sanitizer contact before entry to a controlled area.
Operators may shorten manual wash time or miss surfaces.Programmed paired wash chambers deliver repeatable spray duration to both hands.
Touching taps after washing can recontaminate clean hands.Sensors initiate every stage without contact with controls or fittings.
Combining soap and sanitizer in one opening can cause dilution or carryover.Dedicated wash and disinfection openings physically separate the two processes.
Exposed tanks and pipes complicate wet-area cleaning.The two-door lower cabinet encloses dosing and utility components beneath the drained basin.
Typische Anwendungen
Food-production hygiene entrancesPharmazeutische UmkleidungsräumeHealthcare support areasHigh-care packaging facilities
Technische Parameter
Typical configurable construction values for an automatic hand wash and disinfection station are listed below.
| Core Material | 304 stainless-steel console and basin with polymer hand-entry liners and sensor-controlled dosing |
|---|---|
| Panel Dicke | 40-80 mm console and service-cabinet sections |
| Effektive Breite | 1200-1800 mm operator-facing station width |
| Maximale Länge | Up to 2100 mm overall station length |
| Stahl facing Dicke | 1.2-2.0 mm stainless console and basin facing |
| Kerndichte | 7950-8050 kg/m³ for stainless-steel construction |
| Thermische Leitfähigkeit | 14 - 16 W / (m · K) für austenitischen Edelstahl |
| Oberfläche Finish | Brushed hygienic stainless with black hand-entry liners and smooth sloped basin |
| Gemeinsamer Typ | Welded drained basin with sealed sensor openings and gasketed two-door service cabinet |
| Customisierung | Verfügbar je nach beabsichtigter Anwendung und Betriebsumgebung. |
Verfügbare Optionen
Wash-only or wash-dry-disinfect sequencesHeated water packageAccess-control output after completed cycleAlternative reservoir and utility connections
Planning a Hand Wash and Disinfection Station specification?
Senden Sie uns Ihre Abmessungen, Installationsbedingungen, Leistungsziele und gewünschte Oberflächenveredelung.
