Complete stainless steel rock wool cleanroom panel

클린룸 벽 및 천장 시스템

스테인레스 스틸 Rock Wool Cleanroom Panel

A mineral-core cleanroom panel faced with AISI 304 or 316L stainless steel, built for hygienic walls and ceilings exposed to frequent disinfection, abrasion and demanding corrosion-control routines.

304 or 316L Stainless Steel
Rock Wool Mineral Core
Frequent-Disinfection Surface
Flush Sealed Connections

견적 요청 제품 찾아보기

상품 소개

Stainless Steel Rock Wool Cleanroom Panels combine durable stainless facings with high-density mineral insulation and closed modular edges. AISI 304 suits many hygienic interiors, while 316L offers greater resistance where chloride-bearing cleaners or process residues are present. Brushed, 2B or BA finishes provide smooth non-porous surfaces that withstand repeated wiping. The enclosed rock wool center contributes rigidity and acoustic comfort without exposing fibres. Flush joints and compatible sealants create a robust wall or ceiling system for high-contact, high-cleaning environments.

주요 기능

AISI 304 and 316L facings resist repeated cleaning better than ordinary painted steel.

Non-porous stainless surfaces reveal residue and support visual hygiene inspection.

Rock wool adds mineral insulation and acoustic damping behind the durable outer skin.

Protected edges prevent cleaning fluids from contacting the fibrous core.

Flush modular joints reduce exposed ledges in frequently disinfected areas.

고객 제품 관심사

Customers must select the correct stainless grade, finish direction, joint sealant and cleaning method for the actual exposure.

Aggressive chloride cleaners can stain or pit an unsuitable stainless grade.316L facings are used where chloride exposure exceeds the practical range of 304.

Rough finishing traps residue and makes wipe marks highly visible.Consistent 2B, BA or directional brushed finishes create predictable cleanable surfaces.

Dissimilar trims can introduce galvanic corrosion at wet interfaces.Compatible stainless or isolated aluminum accessories prevent direct dissimilar-metal contact.

Cleaner can enter a damaged panel edge and reach the mineral core.Continuous welded, folded or framed closures protect all perimeter interfaces.

일반적인 응용 프로그램

Pharmaceutical washing and preparation roomsBiotechnology production suitesFood-processing hygiene zonesHospital sterile support areasChemical and high-cleaning laboratories

기술 매개변수

Common specifications for stainless steel and rock wool cleanroom panels are listed below.

핵심 재료	Hydrophobic rock wool
패널 두께	50, 75 또는 100 mm
유효 폭	1000, 1180 or 1290 mm
최대 길이	6000 mm
강철 면면 두께	0.60, 0.80 or 1.00 mm stainless steel
코어 밀도	100 - 140 kg / m 3
열전도도 (Thermal Conductivity)	0. 039 - 0. 043 W / (m · K)
표면 마무리	AISI 304 or 316L stainless steel in 2B, BA or brushed finish
접합 유형	Flush framed connection with hygienic silicone seal
사용자 정의	사용 대상 어플리케이션 및 운영 환경에 따라 사용 가능

사용 가능한 옵션

304 또는 316 L 등급2B, BA or brushed faceStainless perimeter profilesMixed stainless and coated-steel faces

Planning a Stainless Steel Rock Wool Cleanroom Panel specification?

치수, 설치 조건, 성능 목표 및 필요한 표면 마감을 보내십시오.
