Cleanroom wall modules
Form insulated partitions with perimeter connections coordinated around door frames, observation windows and corners.
PRODUCT GALLERYST
Product view
Cleanroom Wall Panels
Handmade Silica Rock Sandwich Panel
Product specifications
| Brand | ST |
|---|---|
| Application | Wall panels / ceiling systems |
| Core structure | Silica rock |
| Edge construction | Grooved profile frame |
| Panel width | Maximum 1180 mm |
| Panel thickness | 50 / 75 / 100 / 150 / 200 mm |
| Maximum panel length | 11,800 mm |
| Facing material | Prepainted galvanized steel (PPGI) / SS304 stainless steel |
| Surface coating | PE / SMP / PVDF / ESD |
| Fire grade | Grade B1 |
| Load-bearing capacity | 100 kg/m² |
Customization availablePanel sizes, metal facing, coating and perimeter or opening-frame details can be customized for your wall and ceiling modules.
Request a quotation
Specify the quantity and configuration in your inquiry.
Handmade Silica Rock Sandwich Panel encloses a silica rock core between metal faces with framed edges for room walls and supported ceilings. The core backs the skins and reduces heat transfer through each module, while the exposed metal surface provides a finished lining for regular cleaning.
A grooved perimeter frame defines the edge of each panel and connects it to adjoining modules and room components. Coordinating these frames around doors, windows and ceiling openings keeps the granular core enclosed and provides finished junctions for sealing.
APPLICATION ENVIRONMENTS
Fit framed modules around the room's openings
Supported ceiling infill
Close the room overhead with framed panels arranged around ceiling supports, lighting and service openings.
PRACTICAL BENEFITS
Insulation inside a finished, framed module
A core behind both metal faces
Silica rock provides an insulating centre and support beneath the skins, combining thermal separation with a cleanable room lining.
An enclosed perimeter
The grooved frame covers the panel edges and gives adjoining modules a defined connection, keeping granular core material behind the finished boundary.
Completed junctions around openings
Matching opening frames and closures extend the finished surface around cut-outs, making those junctions accessible for sealing and cleaning.
SELECTION GUIDE
Coordinate the module frames and surface finish
Frames around doors and ceiling services
Match the panel perimeter and opening-frame details with adjoining doors, windows, ceiling supports and service penetrations.
Facing and cleaning routine
Select the metal facing and coating for the room's cleaning procedure and surface exposure.
PRODUCT QUESTIONS
Questions about framed silica rock panels
What core does this handmade version use?
It uses silica rock, the same core type as the machine-made silica rock panel. Each version keeps its own frame construction and specification table.
How are cut openings finished?
Opening frames or closure profiles cover the cut core and provide a junction to seal against the metal facing and the installed component.
