Wide corner coverage
The cover spans both adjoining faces so the meeting edges sit behind a continuous finishing profile.
PRODUCT GALLERYST
Product view
Cleanroom Accessories
75 × 75 mm Corner Cover
Product specifications
| Brand | ST |
|---|---|
| Model | ST-XC-5020 |
| Application | Decorative edge finishing |
| Thickness | 1.2 mm |
| Length | 6 m per piece |
| Surface treatment | Anodizing / fluorocarbon spraying / electrophoretic coating |
| Tensile strength | ≥175 MPa |
| Proof strength | ≥130 MPa |
| Coating indentation resistance | ≥80 |
Customization availableSpecifications can be customized to your requirements.
Request a quotation
Specify the quantity and configuration in your inquiry.
75 × 75 mm Corner Cover wraps the two faces of a right-angle junction to conceal adjoining edge details under a continuous metal finish. Its wide legs conceal the adjoining edge details, giving the corner a continuous metal cover rather than leaving the panel ends exposed.
The profile has longitudinal grooves and shaped returns along its edges. These details form the visible trim surface; the section drawing shows the stepped shape to match when fitting it around the corner.
FEATURES AND BENEFITS
Complete a broad corner junction
A defined trim surface
Longitudinal grooves and formed edges give the cover its own decorative detail along the corner run.
APPLICATIONS
Where it is used
Panel wall corners
Finish exposed right-angle corners where a wide cover is needed over the adjoining panel edges.
Decorative enclosure returns
Use around compatible right-angle returns to conceal unfinished meeting edges and continue the metal trim.
INSTALLATION AND SELECTION
Allow for the shaped section
Corner fit
Match the right-angle junction and the stepped edge returns to the adjoining surface detail before fixing the cover.
Trim continuity
Align the longitudinal grooves between lengths and make neat joints at the ends of the corner run.
FAQ
Common questions
How does it finish the corner?
Its two wide faces wrap the right-angle junction and cover the meeting edges of the adjoining surfaces.
Is the section a plain flat angle?
The cover has longitudinal grooves and small shaped returns. The dimension drawing retains these section details for matching the installation.
