Managed cycle progression
Concentration monitoring and adjustable cycle time support the defined treatment sequence for the prepared load.
PRODUCT GALLERYST
Product view
Cleanroom Equipment
Vaporized Hydrogen Peroxide Pass Box
Product specifications
| Brand | ST |
|---|---|
| Chamber cleanliness | ISO 5 (Class 100) |
| Filter efficiency | ≥99.995% |
| Airflow | Vertical unidirectional |
| Air velocity | 0.45 m/s ±20% |
| Enclosure | Brushed 304 stainless steel |
| Work chamber | Mirror-finished 316 stainless steel |
| Decontaminant | 30% hydrogen peroxide solution |
| Spore reduction | 6-log for Geobacillus stearothermophilus and Bacillus atrophaeus |
| Cycle time | ≤120 min |
| Residual hydrogen peroxide | ≤1 ppm |
| Noise | ≤65 dB(A) |
| Compressed air | 0.6–0.8 MPa |
| Power supply | 220 V, 50 Hz |
| Controls | Electronic door interlock; adjustable cycle time; concentration monitoring; fault alarms; LCD process display; automatic residual decomposition |
| Dimensions | Custom load and installation dimensions |
Customization availableSpecifications can be customized to your requirements.
Request a quotation
Specify the quantity and configuration in your inquiry.
Vaporized Hydrogen Peroxide Pass Box transfers compatible materials through an enclosed decontamination cycle before collection in the receiving room. Electronic interlocking separates loading, treatment and unloading so a material handover does not create an open passage through the partition.
The chamber combines monitored hydrogen peroxide treatment with filtered vertical airflow and residual-vapor decomposition. Its display and alarms make cycle progress and abnormal conditions visible to the operator.
FEATURES AND BENEFITS
How it helps
Residual-vapor removal
Automatic decomposition provides a separate step between treatment and collection.
Cleanable load space
The stainless steel work chamber provides an accessible surface for cleaning between loads.
APPLICATIONS
Where it is used
Pharmaceutical material entrances
Introduce suitable tools and materials through the established decontamination procedure before controlled production.
Laboratory transfer boundaries
Use an enclosed cycle for compatible materials moving between designated laboratory zones.
SELECTION GUIDANCE
Choosing the configuration
Loading and material compatibility
Arrange packaging and items so the treatment can reach the required surfaces, and use the cycle established for that load.
Installation envelope
Custom chamber size must include loading clearance, service access and the required compressed-air and electrical connections.
