Cleanroom Ductwork & Accessories
| Brand | ST |
|---|---|
| Function | Terminal supply-air volume adjustment |
| Connection | Rectangular flanged connection |
| Configuration | Matched to the terminal inlet |
| Customization | Dimensions and connection arrangement |
Customization availableSpecifications can be customized to your requirements.
Specify the quantity and configuration in your inquiry.
Gel-Seal Terminal Regulating Damper adjusts the supply entering a compatible gel-seal filter terminal. The separate inlet component allows airflow balancing while leaving the filter seating and perimeter gel interface in their intended positions.
MODELS AND DIMENSIONS
| Damper size, mm |
|---|
| 200 × 200 × 190 |
| 320 × 200 × 190 |
| 320 × 250 × 190 |
| 400 × 200 × 190 |
MODEL DIFFERENCES
The square option suits the smaller connection; the wider rectangular bodies fit terminals needing a different inlet geometry. Match the inlet dimensions and available pressure rather than choosing only by the common body depth.
FEATURES AND BENEFITS
The accessible mechanism changes the inlet opening without using the filter seal as an airflow-control component.
The damper can be selected alongside the housing, filter and diffuser according to the existing terminal connection.
APPLICATIONS
Set individual outlet airflow during installation or planned rebalancing.
Replace the matched regulating component while retaining the compatible filter housing.
SELECTION GUIDANCE
Select the flange opening and access direction together with the terminal, keeping the operating point reachable above the finished ceiling.
