Loads too wide for a personnel doorway
Opening both leaves provides more passage space for trolleys, larger containers and assembly items.
PRODUCT GALLERYST
Product view
Cleanroom Doors & Windows
Melamine Resin Panel Cleanroom Door-1
Product specifications
| Brand | ST |
|---|---|
| Model | ST-D-12 |
| Opening styles | Sliding / swing |
| Door frame | 2.0 mm aluminum alloy |
| Door panel | 50 mm melamine resin panel |
| Hardware | Stainless steel lock; aluminum alloy hinges |
| Standard door size | 1500 × 2100 mm |
| Standard vision panel | 400 × 600 mm; double-glazed |
| Optional upgrades | Electronic interlock / door closer / powered door closer |
| Size customization | Custom dimensions available |
Specifications can be customized to your requirements.
Request a quotation
Specify the quantity and configuration in your inquiry.
Melamine Resin Panel Cleanroom Door-1 provides a two-leaf entrance for clean preparation, assembly and packing rooms that need to receive trolleys or larger items as well as staff. Opening both leaves gives a wider route for bringing a load into the room, reducing the need to break it into smaller items simply to pass through a narrow personnel doorway. The resin-panel faces can be wiped during routine cleaning after repeated handling at the entrance.
The aluminum frame connects the door to the surrounding partition, and the vision panels help operators check the adjoining space before moving a load through. Sliding and swing versions let the entrance fit the available opening space, with optional closers for closing after passage and electronic interlocking for linked room entrances.
PRACTICAL BENEFITS
Bring materials in through the room entrance
Handling marks at a busy transfer point
Wipeable resin-panel faces allow the entrance to be cleaned along with the workroom surfaces.
Moving a load toward an unseen corridor
The two vision panels give a view across the closed entrance, helping staff check for approaching people before transfer.
APPLICATION ENVIRONMENTS
Rooms receiving material and equipment loads
Component preparation and assembly rooms
Use the two-leaf entrance to receive work trolleys and larger components without dividing every delivery into hand-carried items.
Clean packing rooms
Provide access for packing materials and finished-product trolleys while keeping the door faces within the regular cleaning routine.
Production rooms with occasional equipment access
Open the wider doorway for moving equipment into or out of the room during setup and maintenance.
SELECTION GUIDE
Allow space for the load and both leaves
Installed passage
Match the usable opening and approach turning room to the widest load; the nominal door width is not the installed clear passage.
Partition interface
Match the aluminum frame connection to the wall thickness so the entrance fits the finished partition opening.
Two-leaf operation
Allow clear swing arcs or sliding travel for the chosen version, and select closing controls around how both leaves are used.
COMMON QUESTIONS
About this two-leaf resin-panel door
What does the two-leaf layout add?
It lets the room entrance accommodate larger loads when both leaves are open, alongside everyday personnel access.
Does an interlock join the two door leaves?
Electronic interlocking coordinates separate linked entrances; it is not a substitute for the hardware that operates or closes each leaf.
Can it be sized for existing material trolleys?
Yes. Custom dimensions can be selected for the load, approach space and surrounding partition.
