Heat passing through an uninsulated curtain
The double-layer PVC and foil insulation form a thermal barrier across the entrance while the curtain is closed.
PRODUCT GALLERYST
Product view
Cleanroom Doors & Windows
Cold Room Insulated Roll-Up Door
Product specifications
| Brand | ST |
|---|---|
| Model | ST-LD-16 |
| Opening style | Roll-up |
| Door curtain | Double-layer PVC with aluminum-foil insulation |
| Seal | Recessed rubber seal |
| Standard door size | 1500 × 2000 mm |
| Temperature range | −18 °C to +57 °C |
| Size customization | Custom dimensions available |
Specifications can be customized to your requirements.
Request a quotation
Specify the quantity and configuration in your inquiry.
Cold Room Insulated Roll-Up Door separates a cold store from the adjoining handling area with a double-layer PVC curtain containing aluminum-foil insulation. The insulated curtain reduces heat transfer across the closed entrance, while the recessed rubber seal limits air movement through perimeter gaps. This helps maintain the cold-store temperature and reduces the extra refrigeration demand caused by a poorly insulated or leaking doorway.
The curtain rolls upward to clear the passage for goods and trolleys. It provides a closable thermal boundary where shelving, nearby equipment or a confined approach leave little space for a swinging leaf or a panel sliding along the wall.
PRACTICAL BENEFITS
Keep an insulated boundary on a goods route
Cold air escaping through door-edge gaps
The recessed rubber seal limits perimeter leakage, helping avoid unnecessary refrigeration load between stock movements.
No clear space beside the entrance
Upward rolling stores the curtain above the opening, leaving the adjacent wall and approach free of a door leaf’s travel.
APPLICATION ENVIRONMENTS
Cold-store entrances used for stock handling
Chilled food storage and preparation areas
Separate ingredient storage from the adjoining handling room while allowing containers and trolleys to pass through.
Frozen-stock picking rooms
Provide an insulated entrance for stock movements in rooms operating within the specified temperature range.
Refrigerated packing and dispatch rooms
Close off the cooled room between product movements where the entrance has limited space for a rigid door leaf.
SELECTION GUIDE
Fit the curtain to the room and passage
Overhead installation space
Allow space for the roll housing and its installation above the required clear opening.
Temperature and room layout
Match the stated temperature range to the operating room and keep the entrance sized for the largest goods load.
Curtain and seal contact
Keep the guides aligned and the rubber seal in continuous contact when closed so the insulated curtain and perimeter seal work together.
COMMON QUESTIONS
About the insulated rolling curtain
What provides insulation in the curtain?
Aluminum-foil insulation is combined with the double-layer PVC curtain; the rubber seal addresses air leakage around the perimeter.
Where does the curtain go when opened?
It rolls into the housing above the entrance, so no side wall travel or floor swing arc is required.
Are custom dimensions available?
Yes. The door can be sized for the cold-store opening, overhead clearance and goods passing through.
