Two leaves to open while handling a load
Powered sliding operation removes the need to pull two hinged leaves out of the way before guiding a trolley through.
PRODUCT GALLERYST
Product view
Cleanroom Doors & Windows
Automatic Single Sliding Door-1
Product specifications
| Brand | ST |
|---|---|
| Model | ST-D-10 |
| Opening style | Double sliding |
| Material | 1.2 mm galvanized steel sheet with a spray-coated finish |
| Standard door size | 1600 × 2400 mm |
| Standard vision panel | 400 × 600 mm; double-glazed |
| Opening methods | Manual / sensor activation / foot switch / access-control system |
| Size customization | Custom dimensions available |
Specifications can be customized to your requirements.
Request a quotation
Specify the quantity and configuration in your inquiry.
Automatic Single Sliding Door-1 uses two sliding leaves to provide a wider entrance for moving trolleys, bulkier materials and equipment into a room. The leaves move apart sideways, opening the route without swinging toward an approaching load. Sensor or foot-switch activation lets the operator request opening while guiding a trolley, reducing the need to leave the load and pull two door leaves by hand.
This arrangement suits room entrances that combine personnel access with larger transfers. Manual and access-control opening are also available, so entry can follow the room's operating routine or permission settings. Double-glazed vision panels help staff check the opposite side before transfer, and the spray-coated galvanized-steel surfaces can be wiped during cleaning.
PRACTICAL BENEFITS
Make larger transfers easier to guide through the entrance
A doorway shared by people and larger items
The two-leaf layout provides an entrance for room access and larger transfers, with door dimensions selected to suit the required clear passage.
Check the approach while positioning a trolley
Vision panels let staff look into the adjoining space before starting a transfer, helping coordinate passage through a shared entrance.
APPLICATION ENVIRONMENTS
Entrances used for larger transfers as well as daily access
Production rooms receiving material trolleys
Use the wider two-leaf arrangement for repeated transfers of larger loads while operators guide the trolley through.
Equipment access to preparation and assembly rooms
Provide powered sliding access where equipment movement would be awkward through a narrower personnel entrance.
Controlled-entry staging rooms
Use access-control activation where larger loads must pass through an entrance whose opening is subject to entry permission.
SELECTION GUIDE
Plan the opening and travel on both sides
The widest load
Match the installed clear width and the approach turning space to the trolley or equipment using the entrance, rather than relying on the nominal door size alone.
Room for both leaves to slide
Keep clear wall space on both sides of the opening so each leaf can move out of the passage.
Opening request during transfer
Position sensor or foot-switch activation where the operator can request opening while keeping control of the load; use access-control activation for restricted entries.
COMMON QUESTIONS
About this two-leaf sliding configuration
How do the door leaves move?
Two leaves slide apart toward opposite sides of the opening, without a hinged swing arc.
What makes this configuration useful for equipment movement?
The two-leaf entrance can accommodate a wider passage, while powered activation lets the operator focus on guiding the load.
Can the door dimensions be customized?
Yes. Door dimensions can be adapted to the required opening and the available sliding clearance.
