Hands occupied with a load
Sensor or foot-switch activation reduces the need to put an item down or release a trolley just to pull the door open.
PRODUCT GALLERYST
Product view
Cleanroom Doors & Windows
Automatic Single Sliding Door
Product specifications
| Brand | ST |
|---|---|
| Model | ST-D-9 |
| Opening style | Sliding |
| Material | 1.2 mm galvanized steel sheet with a spray-coated finish |
| Standard door size | 1000 × 2400 mm |
| Standard vision panel | 400 × 600 mm; double-glazed |
| Opening methods | Manual / sensor activation / foot switch / access-control system |
| Size customization | Custom dimensions available |
Specifications can be customized to your requirements.
Request a quotation
Specify the quantity and configuration in your inquiry.
Automatic Single Sliding Door moves one leaf along the wall to open a room entrance without a swinging panel projecting into the passage. Sensor or foot-switch activation lets staff carrying items or guiding a trolley request opening without stopping to pull a door handle. This helps at production and preparation-room entrances where repeated transfers interrupt work or a swing door would occupy the approach space.
Manual operation and access-control activation are also available, allowing the opening method to match the room's daily use and entry permissions. The double-glazed vision panel provides a view of the other side, while the spray-coated galvanized-steel face can be wiped during routine cleaning.
PRACTICAL BENEFITS
Keep transfers moving without a swinging leaf
Limited space beside a busy entrance
The leaf travels sideways rather than swinging into the approach, leaving the area in front of the door free of a swing arc.
Different access needs at different rooms
Sensor activation suits routine approach, a foot switch gives a deliberate request, and an access-control system can govern who may initiate opening.
APPLICATION ENVIRONMENTS
Room entrances with repeated personnel and material movement
Clean production and preparation rooms
Use sensor or foot-switch opening where operators move components and work trolleys between the room and corridor.
Packing and material staging rooms
Provide a sliding entrance where staff carry items through repeatedly and need to avoid stopping to pull a leaf.
Rooms with controlled entry
Connect opening to the access-control system where passage should depend on entry permission rather than approach alone.
SELECTION GUIDE
Match activation and travel space to the workflow
Space for the sliding leaf
Allow sufficient clear wall length for the leaf to travel fully open, keeping nearby equipment out of its path.
Activation position
Place the sensor or foot switch where the approaching operator can trigger opening without awkwardly repositioning a load.
Required passage width
Size the installed clear opening for the people and trolleys using the route; the frame and leaf position affect usable width.
COMMON QUESTIONS
About the automatic single-leaf entrance
Does the leaf swing into the corridor?
No. It slides sideways along the wall, so the entrance does not need a door-leaf swing arc.
Must someone touch a handle to request opening?
Sensor and foot-switch activation provide alternatives to hand operation. Access-control activation can be used where entry permission is required.
Can the door dimensions be customized?
Yes. Custom dimensions are available to suit the room opening and the space available for leaf travel.
